Universal Columns
Welcome to our universal column steel sections free CAD downloads page! Here you'll find a complete set of universal column shapes currently manufactured and supplied in Southern Africa. Sort the table below according to any property and select a CAD file to download using the reference links in the left-most column.
Like our content and want to show your appreciation? Well, you can now buy us a coffee! Thank you for your support!
| Section Reference | Mass per Metre | Depth of Section | Width of Section | Web Thickness | Flange Thickness | Root Radius |
|---|---|---|---|---|---|---|
| (Click on link to download) | kg/m | h mm | b mm | tw mm | tf mm | r mm |
| HR-UC 152x152x23 | 23.0 | 152.4 | 152.4 | 6.1 | 6.8 | 7.6 |
| HR-UC 152x152x30 | 30.0 | 157.5 | 152.9 | 6.6 | 9.4 | 7.6 |
| HR-UC 152x152x37 | 37.0 | 161.8 | 154.4 | 8.1 | 11.5 | 7.6 |
| HR-UC 203x203x46 | 46.1 | 203.2 | 203.2 | 7.3 | 11.0 | 10.2 |
| HR-UC 203x203x52 | 52.0 | 206.2 | 203.9 | 8.0 | 12.5 | 10.2 |
| HR-UC 203x203x60 | 60.0 | 209.6 | 205.2 | 9.3 | 14.2 | 10.2 |
| HR-UC 203x203x71 | 71.0 | 215.9 | 206.2 | 10.3 | 17.3 | 10.2 |
| HR-UC 203x203x86 | 86.1 | 222.3 | 208.8 | 13.0 | 20.5 | 10.2 |
| HR-UC 254x254x73 | 73.1 | 254.2 | 254.0 | 8.6 | 14.2 | 12.7 |
| HR-UC 254x254x89 | 88.9 | 260.4 | 255.9 | 10.5 | 17.3 | 12.7 |
| HR-UC 254x254x107 | 107.0 | 266.7 | 258.3 | 13.0 | 20.5 | 12.7 |
| HR-UC 254x254x132 | 132.0 | 276.4 | 261.0 | 15.6 | 25.1 | 12.7 |
| HR-UC 254x254x167 | 167.0 | 289.1 | 264.5 | 19.2 | 31.7 | 12.7 |
| HR-UC 305x305x97 | 96.9 | 307.8 | 304.8 | 9.9 | 15.4 | 15.2 |
| HR-UC 305x305x118 | 118.0 | 314.5 | 306.8 | 11.9 | 18.7 | 15.2 |
| HR-UC 305x305x137 | 137.0 | 320.5 | 308.7 | 13.8 | 21.7 | 15.2 |
| HR-UC 305x305x158 | 158.0 | 327.2 | 310.6 | 15.7 | 25.0 | 15.2 |
| HR-UC 305x305x198 | 198.1 | 339.9 | 314.5 | 19.1 | 31.4 | 15.2 |
